Apantac CRESCENT MX Multiviewers

Product Description

Cost-Effective 32x4 3G and 32x2 UHD Multiviewers

Key Features

  • Low latency - single frame processing delay
  • Low energy - only uses 75W of power
  • Accepts 32 auto-detect 3G/HD/SD-SDI inputs
  • 2 independent HDMI 2.0 and SDI (12G and 3G) outputs
  • Output resolution up to UHD @60Hz
  • Maximum of 16 windows per output
  • Every input can be duplicated up to 32 times
  • Every input is available to both outputs
  • Windows can be sized and moved freely
  • Decodes up to 16 embedded audio per SDI input
  • Total of 256 audio meters
  • Ethernet for configuration and external control
  • Dynamic UMD/Label and Tallies (TSL)
  • 2 digital and 2 analog clocks can by synced with LTC or NTP
  • 64 GPIs for tallies, count up/down triggers or preset recalls
  • Borders can be turned on or off
  • Visual alarm tags for format, video/audio presence
  • Audio monitoring outputs - stereo, AES, SDI or HDMI
  • 2 RU with redundant power supply
  • 3 year limited warranty

Product Code

Product Name

Add to Basket

Apantac CRESCENT MX Multiviewers
Mx-32x2-UHD
Cost Effective 32x2 3G/HD/SD-SDI input Multiviewer with 2 UHD Outputs

MX-32
Cost Effective 32x4 3G/HD/SD-SDI Multiviewer
